PRODUCT
GTS600 3D Printer
One Shaped High Volume Complex Structure Full format, More Precision, Greater Stability Designed for industrial Clients
Technical Parameter
|
Materials |
Titanium Alloys, Aluminum Alloys, Superalloys, CoCr Alloys, Stainless Steel, Die Steel, Copper Alloys, etc. |
|
Build Size |
605mm×605mm×650mm (L×W×H) |
|
Laser Type |
IPG 500W×4 |
|
Scanning System |
Scanlab High-speed Galvanometer |
|
Beam Focus System |
SILL F-theta Field Lens |
|
Beam Quality |
M2<1.1 |
|
Spot Diameter |
70~100μm ( size adjustable ) |
|
Max Scanning Speed |
7m/s |
|
Layer Thickness |
20~100μm (Layer thickness adjustable ) |
|
Platform Preheat Temperature |
RT+20~200℃ |
|
Powder spreading |
Dual way variable speed powder spreading |
|
Gas |
Ar/N2 |
|
Oxygen Content |
≤100ppm |
|
Efficiency |
100cm3/h (dependent on the shape. size, material and parameters) |
|
Host Dimension |
5100mm×4700mm×3850mm (W×D×H) |
|
Installation Dimension |
8000mm×7000mm×4500mm (W×D×H) |
|
Power Supply |
AC380V |
|
Power Consumption |
16KW |
|
Weight |
About 16400KG |
