GTScan U High Accuracy 3D Scanner
GTScan U series is the product portfolio for high accuracy industrial applications, whose accuracy and resolution can be up to 0.02mm and scanning speed up to 1.6 million points per second.
It can be widely used in the applications within automotive, aerospace, aviation, energy, etc.
Specifications
|
Product type |
GTScan U7 |
GTScan U11 |
GTScan U13 |
|
Measurement rate |
480,000 points/sec |
1,360,000 points/sec |
1,600,000 points/sec |
|
Scan range |
320*250mm |
320*250mm |
320*250mm |
|
Laser |
14 blue cross laser lines + 1 blue laser line |
22 blue cross laser lines + 1 blue laser line |
26 blue cross laser lines + 1 blue laser line |
|
Laser category |
Class II (eye safety) |
||
|
Min. resolution |
0.02mm |
||
|
Wireless arithmetic unit |
Support |
||
|
Photogrammetry |
Support |
||
|
Round hole flash test |
Support |
||
|
Accuracy |
Max. 0.02mm |
||
|
Vol. accuracy |
0.02-0.03mm/m |
0.02-0.025mm/m |
0.02mm/m |
|
Standard distance |
350mm |
||
|
The depth of field |
250mm |
||
|
Compatible software |
Geomagic, PolyWorks, NX, CATIA V5, SolidWorks, Pro/E, Inventor, Alias, 3ds Max, Maya, Solid Edge |
||
|
Data transfer |
USB3.0/Wifi |
||
|
Temperature |
-20℃~40℃ |
||
|
Humidity |
10%~90% |
||
Features
- Accuracy up to 0.02mm
- Resolution up to 0.02mm
- Scanning speed up to 1.6 million points per second
- Built-in photogrammetry system
- Stable measurement accuracy
- Globle precison control
